ETL Pipeline

ETL stands for Extraction, Transformation, Loading. We have an ETL pipeline for taking in the RAW videos given to us by the hospital, extracting and storing the frames from it, and maintaining CSV files pointing to these frames with the frame status, such as timestamp, disturbed, etc. This allows us to take the information from the CSVs and make a dataset using them that contains paths to the previously extracted frames instead of re-extracting the frames again from the videos, which is computationally very expensive. All the ETL pipeline, data extraction and modification happens in the ‘trishul’ server. The ETL Pipeline contains these parts:

ETL Pipeline Flowchart

  1. Video Upload: Hospital Staff uploads the videos to Amrita Drive

  2. Video Download and Gsheet Sync: Script downloads all newly uploaded videos and runs at 5am every morning. The script is stored at https://github.com/Amrita-Medical-AI/server-infrastructure/blob/main/eusml-fatty_liver-drive-sync.sh and refer to the documentation of the https://github.com/Amrita-Medical-AI/server-infrastructure repo to get it working.

    The downloaded videos at the time of writing is saved at /data/eusml/raw_data for EUSML and at /data/fatty_liver/raw_data. The other configs can be found in the eusml-fatty_liver-drive-sync.sh script. 3. ETL This is the mian part of the ETL Pipeline. Code is stored at https://github.com/Amrita-Medical-AI/eusml-ETL-pipeline

    3.1 Patients and Label sheet Update We stored the time stamp labels from DynamoDB after processing it in labels.csv. The patient specific data like cancer type, cap score etc are stored in patients.csv. These files are present in /data/{eusml, fatty_liver}/master-dataset/Data.

    Run labels_generator/{eus,liver}_generator.py_

    3.2 Video Frame Extraction *The video frame extracation is done by the scripts *eus_main.py and liver_main.py and their configs are stored in the files eus_config.yaml and liver_config.yaml

    3.3 Pre-processing and metadata calculation The preprocessing script takes the extracted frames and saves them after preprocessing. It also creates the metadata files for the preprocessing. Run the script using pre-process.py and the project and configs for it should be set in preprocess_config.yaml.

Important Paths:

EUSML:

  • Raw video Directory: /data/eusml/raw_data
  • Master Dataset: /data/eusml/master-dataset
  • Patient, labels and metadata CSVs: /data/eusml/master-dataset/Data
  • Patient Frame CSVs: /data/eusml/master-dataset/Frames

Fatty Liver:

  • Raw video Directory: /data/fatty_liver/raw_data
  • Master Dataset: /data/fatty_liver/master-dataset
  • Patient, labels and metadata CSVs: /data/fatty_liver/master-dataset/Data
  • Patient Frame CSVs: /data/fatty_liver/master-dataset/Frames

Support Scripts

For detailed information about support scripts, tools, and applications, see the Support Scripts page.
